Polyken942 3-ply pipe wrapping tape

FOB Reference Price:Get Latest Price
US $2.75-5.51 / Roll | 300 Roll/Rolls (Min. Order)
Supply Ability:
15000 Square Meter/Square Meters per Day
Port:
Qingdao Port
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Shandong, China (Mainland)
Brand Name:
POLYKEN
Model Number:
Polyken 942
Color:
Black
Thickness:
32mils(0.8mm)
Length:
50ft(15M)100ft(30M),200ft(61M)
Width:
2"(50mm),,4"(100mm),6"(150mm),9"(228mm),12"(305mm)18" (457mm)
Inner layer:
Butyl rubber
Carrier film:
PE
Outer layer:
Butyl rubber
Features:
Forming a sleeve-type coating
Test method:
ASTM D 1000/ EN 12068/ ASTM E 96
Using for:
Underground steel oil and gas pipeline anticorrosion
Packaging & Delivery
Packaging Details
export cartons
Delivery Time
Shipped in 3 days after payment

Polyken942 3-ply pipe wrapping tape

Product Description

System Description

The POLYKEN 942&955 System is a multilayer coating system designed for the corrosion protection of pipelines

operating in highly corrosive environments and exposed to high mechanical stresses that may be present particularly on large diameter pipes. The system consists of POLYKEN#1027 liquid adhesive,POLYKEN #942 three-ply anti-corrosion inner layer and POLYKEN #955 mechanical outer layer and is fully certified to the DIN 30672 and EN12068 standards. The 3-ply adhesive system produces a strong cohesive bond to the primed steel surface, at the spiral overlap and to the mechanical outer layer. The tough mechanical properties of the outer layer provide protection to the pipes during handling and installation.



Features



- Fully amalgamating overlapping areas

-Forming a sleeve-type coating

- Impermeable to oxygen and moisture

- Resistant to soil stress

-Superior in-ground performance

-Long-term in-ground performance

-Uniform coating thickness

-Plant coating quality with in-situ application

-Low cathodic protection-current requirements

-Saving cost over the life of the pipeline

-Compatible with all pipe diameters and generic plant coating systems



Properties



PROPERTIESUNITTEST METHODInner layer-3ply tape
POLYKEN 942-32
Total ThicknessmilASTM D 100032mil(0.8mm)
Tensile strengthN/cmASTMD1000112
Elongation at break%ASTMD1000650
Peel strength to primed steel at 23 ℃N/cmEN 1206815
at 50℃Annex C1.3
Peel strength tape to tape at 23 ℃ N/cmEN 1206825
at 50℃Annex B3.5
Peel strength layer to layer EN 12068
-Inner to InnerN/mm1.5
-Outer to Inner 2
-Outer to Outer 0.5
Dielectric strengthKv/mmASTMD14932
Insulation    ResistanceOhm.m²EN 120681012
Water Vapor Transmissiong/ m2 /24hASTM E 960.1
Water Absorption%ASTM D 5700.08
Impact resistance     at 23°JEN 1206818
Cathodic disbandment at 23°cmmEN 1206815
at 50°c30
Lap shear strength   at 50℃N/mm2EN 120680.05



Ordering Information





Eg.: POLYKEN 942-32  4"×100'

942

Product Model No.

Standard ordering options

32

Total thickness in mils

32mils(0.8mm)

BLK

Tape backing color

Black (BLK)

4

Tape width in inches

2"(50mm),,4"(100mm),6"(150mm),9"(228mm),12"(305mm)18" (457mm)

100

Tape roll length in feet

50ft(15M)100ft(30M),200ft(61M)

Certifications

1. CNPC Test Report

2. DVGW Test Report

3. SGS Test Report

4. ISO 9001 / ISO 14001 Certification
